SCILOGEX OS40-Pro (40L) LCD Digital Overhead Stirrer

SCILOGEX OS40-Pro (40L) LCD Digital Overhead Stirrer
Cat. No. 840203019999

SCILOGEX OS40-Pro Overhead LCD Digital Stirrer, 40L Capacity, 100-220V 50/60Hz, US Plug (stand included, order impellers separately)

Qty:

1,250.00 1250.0 USD

1,250.00

This product will ship within 1-2 weeks.
Credit Cards

For more information please call +1 (860) 436-9221

or email us at info@scilogex.com

OS40-Pro LCD Digital Overhead Stirrer Features:



  • ORDER AND RECEIVE A FREE STAND! Part# 18900131
  • High reliability and outstanding performance
  • Accurate microprocessor stirring speed control guarantees speed precision
  • Remote function provide PC control and data transmission
  • Provides constant speed even with changes in viscosities of the samples
  • Anti-spill microprocessor control slow start up prevents spillage and splashing
  • Safety circuits allow for safe stop function in anti-stall or overload conditions
  • A through-shaft design allows for easy adjustment of the impeller position
  • Brushless DC motor for long life, maintenance free and explosion proof
  • Large chuck diameter for many shaft types
  • Torque trend display for real-time information on viscosity changes
  • LCD display for precise monitoring of set and actual speeds, a wide range of speed from 50 to 2200rpm with control accuracy of ±3rpm.
  • Set value and actual value can be displayed for real-time monitoring of torque and speed
  • Over torque protection automatically stops the motor
  • Availability of auto-restart function in case of power loss for overnight operations
  • Pass through stirrer rods accepted
  • PC software control via RS232 interface, for control and documenting all measured values via PC. Download software here
  • cTUVus approved for UL and CSA
  • 2 YEAR WARRANTY
OS40-Pro (40L) LCD Digital Overhead Stirrer



OS40-Pro LCD Digital Overhead Stirrer Specifications



Maximum stirring capacity40 Liters
Maximum torque60Ncm
Viscosity maximum50000mPas
Speed range50-2200rpm
Speed/Torque displayLCD
Speed display accuracy± 3rpm
Speed display resolution± 1rpm
Chuck diameter range0.5-10mm
Dimensions3.3W x 8.7H x 7.3Dinches
Motor typebrushless DC motor
Motor rating input120W
Motor rating output100W
Weight5.5lbs
Voltage/Power100-220V, 50/60 Hz/130W
Overload protection displayLED lights
Data connectorRS232
Protection classIP21
Permissible ambient temperature and humidity5-40°C, 80%RH








SCILOGEX OS40-Pro (40L) LCD Digital Overhead Stirrer Accessories:
Cross stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 50mm diameter.
Cat. No.:
18900071
Description:

Cross stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 50mm diameter.

20.00
Straight stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 60mm diameter.
Cat. No.:
18900072
Description:

Straight stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 60mm diameter.

54.00
Paddle stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 67mm width x 67mm height.
Cat. No.:
18900073
Description:

Paddle stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 67mm width x 67mm height.

52.00
Centrifugal stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 90mm diameter.
Cat. No.:
18900074
Description:

Centrifugal stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 90mm diameter.

52.00
Cross stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 65mm diameter.
Cat. No.:
18900075
Description:

Cross stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 65mm diameter.

82.00
Straight stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 70mm diameter.
Cat. No.:
18900076
Description:

Straight stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 70mm diameter.

82.00
Paddle stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 67mm width x 67mm height.
Cat. No.:
18900077
Description:

Paddle stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 67mm width x 67mm height.

82.00
Centrifrugal stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 90mm diameter.
Cat. No.:
18900078
Description:

Centrifrugal stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 90mm diameter.

82.00
Plate stand with support rod and clamp. Plate size 12inches x 8inches. Rod length 26inches.
Cat. No.:
18900131
Description:

Plate stand with support rod and clamp. Plate size 12inches x 8inches. Rod length 31inches.

180.00
