SCILOGEX OS40-Pro (40L) LCD Digital Overhead Stirrer

SCILOGEX OS40-Pro (40L) LCD Digital Overhead Stirrer
Cat. No. 840203019999

SCILOGEX OS40-Pro Overhead LCD Digital Stirrer, 40L Capacity, 100-220V 50/60Hz, US Plug (stand included, order impellers separately)

1,055.00 1055.0 USD

1,055.00

Credit Cards

OS40-Pro LCD Digital Overhead Stirrer Features:

  • ORDER AND RECEIVE A FREE STAND! Part# 18900131
  • Accurate microprocessor stirring speed control guarantees speed precision
  • Anti-spill microprocessor control slow start up prevents sample spills
  • A through-shaft design allows for easy adjustment of the impeller position
  • Large chuck diameter for many shaft types
  • LCD display and control. Set value and actual value can be displayed for real-time monitoring of torque and speed
  • Over torque protection automatically stops the motor
  • Pass through stirrer rods accepted
  • PC software control via RS232 interface, for control and documenting all measured values via PC. Download software here
  • 2 YEAR WARRANTY



OS40-Pro LCD Digital Overhead Stirrer Specifications

Maximum stirring capacity:40 Liters
Maximum torque:60Ncm
Viscosity maximum:50000mPas
Speed range:50-2200rpm
Speed display accuracy:± 3rpm
Speed display resolution:± 1rpm
Chuck diameter range:0.5-10mm
Dimensions:3.3W x 8.7H x 7.3Dinches
Motor rating input:120W
Motor rating output:100W
Weight:5.5lbs
Voltage:110Volts 60Hz, 130W
SCILOGEX OS40-Pro (40L) LCD Digital Overhead Stirrer Accessories:
Cat. No. Description
18900071
Cross stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 50mm diameter.
17.50

Cross stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 50mm diameter.

18900072
Straight stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 60mm diameter.
44.00

Straight stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 60mm diameter.

18900073
Paddle stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 67mm width x 67mm height.
44.00

Paddle stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 67mm width x 67mm height.

18900074
Centrifugal stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 90mm diameter.
44.00

Centrifugal stirrer, 316L stainless steel. Shaft 400mm long x 8mm diameter. Impeller 90mm diameter.

18900075
Cross stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 65mm diameter.
67.00

Cross stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 65mm diameter.

18900076
Straight stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 70mm diameter.
67.00

Straight stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 70mm diameter.

18900077
Paddle stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 67mm width x 67mm height.
67.00

Paddle stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 67mm width x 67mm height.

18900078
Centrifrugal stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 90mm diameter.
67.00

Centrifrugal stirrer, PTFE coated. Shaft 300mm long x 6mm diameter. Impeller 90mm diameter.

18900131
Plate stand with support rod and clamp. Plate size 12inches x 8inches. Rod length 26inches.
147.00

Plate stand with support rod and clamp. Plate size 12inches x 8inches. Rod length 31inches.
