So-Low Explosion Proof-Manual Defrost Refrigerators

https://www.scilogex.com/web/image/product.template/2000/image_1920?unique=0ed0ed6
Units come standard with adjustable mechanical thermostat, locking doors, 1 year parts and labor warranty and meets NSPA and OSHA guidelines for Hazardous Locations, Class 1, Division 1, Division II, Group C & D. MADE IN USA. NATIONWIDE SERVICE.

$ 5,380.00 $ 5,380.00 In stock
In Stock

Weight: 90.7 kg

$ 3,690.00

Currently Out-of-Stock

  • Model

This combination does not exist.

LTL Shipping
Contact Us
Request a Quote
In Stock
Get the best price
for your organization today

Product Specifications:

Model Temperature Range Capacity Dimensions Exterior w x d x h (inches) Exterior w x d x h (cm) Interior w x d x h (inches) Interior w x d x h (cm)
DHH4-14SDRX 1°C to 10°C 14 Cubic Ft. / 396 L ➤ 23.5" x 24.5" x 73" — — 50 x 42 x 160
DHH4-17SDRX 17 Cubic Ft. / 481 L 30.75" x 28.5" x 67.7" 78 x 72 x 172 26.25" x 20.75" x 58.5" 67 x 53 x 149
DHH4-20SDRX 20 Cubic Ft. / 566 L 34.75" x 29" x 74.50" 88 x 74 x 189 24.75" x 20.75" x 65.2" 63 x 53 x 166
DHH4-30SDRX 30 Cubic Ft. / 849 L 35.75" x 35" x 77.5" 90 x 88 x 196 32" x 22.5" x 65" 81 x 57 x 165
MV4-6UCXR 5 Cubic Ft. / 141 L 23.75" x 23.75" x 32.25" — 20.25" x 17.25" x 27" —

Features:

Feature DHH4-14SDRX DHH4-17SDRX DHH4-20SDRX DHH4-30SDRX MV4-6UCXR
Thermostat Microprocessor digital Microprocessor temp controller Microprocessor temp controller Microprocessor temp controller Microprocessor digital
Alarms High/Low temp High/Low + power failure + audible/visual High/Low + power failure + audible/visual High/Low + power failure + audible/visual High/Low temp
Display Digital (Min/Max reset) Digital display Digital display Digital display Digital (Min/Max reset)
Alarm Relay Dry contacts Remote alarm contacts Remote alarm contacts Remote alarm contacts Dry contacts
Compressor Hermetic 1/5 HP 1/2 HP 1/2 HP Hermetic
Air Circulation Forced air Fan N/A N/A Direct cooling
Defrost Cycle Cycle Manual Manual Cycle
Doors 1 door, keyed Single solid, key lock Single solid, locking Single solid, locking Lockable, keyed
Door Material Insulated steel — — — —
Casters No N/A Four adjustable Four adjustable No
Legs 4 leveling Four leveling N/A N/A 2 front leveling
Shelves 5 adjustable 5 shelves Adjustable epoxy coated Adjustable epoxy coated 3 adjustable
Insulation High density urethane High density urethane foam Polyurethane foam Polyurethane foam EPA H.D.U.F.
Refrigerant R600a R-600A R134A CFC free R134A CFC free R600a
Evaporator — N/A Cold wall Cold wall —
Voltage 115V / 60Hz / 1Ph 115/60/1 115/60/1 115/60/1 115V / 60Hz / 1Ph
Running Amps 3A 3 7/15 7/15 1.2A
Supply Plug Hardwired Not supplied (hardwire) None / hardwired None / hardwired Hardwired
Shipping Weight 200 lbs 240 lbs 575 lbs 575 lbs 130 lbs
Certifications ETL, NFPA/OSHA ETL Listed N/A N/A ETL, NFPA/OSHA
Warranty 2 Years 2 Years parts & labor 12 months + 4 yr compressor 12 months + 4 yr compressor 2 Years

Additional Resources and Information

Downloadable PDFs


DHH4-17SDRX Specification Data Sheet


DHH4-20SDRX Specification Data Sheet


DHH4-30SDRX Specification Data Sheet


MV4-6UCXR Specification Data Sheet


DHH4-14SDRX Specification Data Sheet
