So-Low Scientific Flammable Material Storage Refrigerators

https://www.scilogex.com/web/image/product.template/6670/image_1920?unique=9b87b6d
Units come standard with adjustable microprocessor, locking doors, 3 year parts and labor warranty and meets NSPA and OSHA guidelines for flammable material storage in general laboratory work areas.

$ 3,100.00 $ 3,100.00 In stock
In Stock

Weight: 39.0 kg

$ 0.00

Currently Out-of-Stock

  • Model

This combination does not exist.

LTL Shipping
Contact Us
Request a Quote
In Stock
Get the best price
for your organization today

Product Specifications:

Specification LRBFS06W1HC LRBFS09W1HC LRBFS12W1HC LRBFS20W1HC SRFfg 3501 SRFfg 5501
Manufacturer LIEBHERR
Type Undercounter Undercounter Undercounter Undercounter Full-size Full-size
Capacity [ Cu. Ft. ] 5.8 cu.ft. 8.1 cu.ft. 11.2 cu.ft. 18.7 cu.ft. 12.1 / 11.1 cu.ft. 19.7 / 18.3 cu.ft.
Capacity [ Liters ] 165 L 229 L 318 L 533 L 344 / 315 L 558 / 517 L
Temperature Range [ °C ] 1°C to 15°C 1°C to 15°C 1°C to 15°C 1°C to 15°C 3°C to 16°C 3°C to 16°C
Temperature Range [ °F ] 34°F to 59°F 34°F to 59°F 34°F to 59°F 34°F to 59°F 38°F to 60°F 38°F to 60°F
Dimensions [ W × D × H ]
Exterior [ Inches ] 24" × 24.25" × 34" 23.75" × 24.5" × 49.25" 23.75" × 24.5" × 64.75" 29.5" × 29.5" × 64.75" 23.6" × 25.75" × 66.3"
29.4" × 30.3" × 66.3"
Interior [ Inches ] 20.25" × 17.25" × 27.75" 18.5" × 17.25" × 42" 18.5" × 17.25" × 57" 23.5" × 22" × 57.25" 18.1" × 16.7" × 57.5"
23.6" × 21.2" × 57.5"
Exterior [ Centimeters ] 59 × 61 × 85 59 × 61 × 125 59 × 61 × 164 74 × 74 × 164 59.7 × 65.4 × 168.4 74.7 × 76.9 × 168.4
Interior [ Centimeters ] 51 × 44 × 70 47 × 44 × 106 47 × 44 × 145 60 × 56 × 145 46 × 42.3 × 146 60 × 53.7 × 146
Electrical Specifications
Specification LRBFS06W1HC LRBFS09W1HC LRBFS12W1HC LRBFS20W1HC SRFfg 3501 SRFfg 5501
Voltage Available 115 Volts 60 Hz 1 Phase 115 V / 60 Hz 115–127 V / 60 Hz
Amperage 15A Dedicated | 1.5A running 15A Dedicated | 2.5A running 15A Dedicated | 3.0A running 15A Dedicated | 3.0A running — —
NEMA Configuration NEMA 5-15 — —
Energy Consumption — — — — 0.63 kWh/day 0.73 kWh/day
EnergyStar Rated — — — — Yes Yes
Certification(s) ETL Listed MET Listed (EX) ETL / ATEX 95
Control Specifications
Specification LRBFS06W1HC LRBFS09W1HC LRBFS12W1HC LRBFS20W1HC SRFfg 3501 SRFfg 5501
Temperature Control Analog control, Digital display (external) Monochrome display, touch buttons
Temp Stability — — — — ±3 °C (gradient 3.6°C / max. fluctuation 3.1°C)
±3 °C (gradient 3.7°C / max. fluctuation 3.0°C)
Temperature Alarm — — — — Visual & audible
Alarm Relay — — — — Volt-free alarm contact (dry contacts)
Power Failure Alarm — — — — When mains power returns
Connectivity Type — — — — SmartModule
Connectivity Solution — — — — Retrofittable
Interface — — — — WiFi / LAN (optional)
General Specifications
Specification LRBFS06W1HC LRBFS09W1HC LRBFS12W1HC LRBFS20W1HC SRFfg 3501 SRFfg 5501
Air Circulation Forced Air
Defrost Method Automatic
Compressor Hermetic Compressor
Primary Refrigerant R600a R600a R290 R290 R600a R600a
Insulation Polyurethane Foam
Opening 1 Front Door
Door Material Insulated Steel Steel
Lockable Door Keyed Lock Mechanical Lock
Access Porthole 1 × Ø 10 mm 1 × Ø 10 mm
Storage Shelves 3 adjustable glass 4 adjustable glass 5 adjustable glass 5 adjustable glass 4 adjustable glass 5 adjustable glass
Shelf Weight Limit 40 lbs. 40 kg (88.2 lbs.)
Exterior Finish Steel, Painted White
Interior Material Molded Polystyrol
Leveling Legs 4 leveling legs Adjustable feet (optional)
Sound Rating 50 dB 48 dB(A) 49 dB(A)
Ambient Temp Range — #ERROR!
Compliance NFPA 45 & 99, Class I Div 2 NFPA 45 & 99, Class I Div 2
ATEX 95 (EU 2014/34/EU), NFPA 45 & 99
Warranty 3 Years Parts & Labor — —
Specifications subject to change without notice. Dimensions for SRFfg models converted from mm. All units feature ignition-source-free interiors per applicable flammable material storage requirements.

​
